01
VOBC PSU/ADU Device
CSIN Tech, succeeded in the localization of PSU, that is the power supply used for VOBC System, which is On-board Controller to automatic train operating for EMU, supplied this device to Incheon Line-2 EMU. Also, we supplied ADU together that assist safe driving of subway through displaying driving information this device is MVB communication that has the function of monitoring and recording inside the vehicle’s state.
-
02
Philippine Manila EMU ATP On-board Signal System
ATP Rack consists of two controller redundancy with Checked Redundancy Mode computing input the value with two computing devices and print only when the input and output values are same. We manufactured and supplied safe On-board Signaling System.
Major Products
-
ATP Rack
ATP Rack is the Safety On-board Signaling System consists of two controller redundancy with Checked Redundancy Mode computing input the value with two computing devices and print only when the input and output values are same.
(Philippine Manila) -
VOBC PSU /
PSU : PSU is a power supply of VOBC.
Aspect Display Device (ADU)
ADU : ADU displays the transmitted information between VOBC and Train Control and Monitoring System. -
ATC/ATP/ATS
It is a next-generation Integrated On-board Signaling System that can process ATC/ATP/ATS three signal processing.
On-board Signaling System -
COMC Unit
It performs the functions of ATP and ATO as a component of On-board Signaling System. -
CTIU Unit
As the component of On-board Signaling System, it receives wayside railway circuit telegram from On-board Pickup Coil and performs the function of transmitting after verifying of telegram ‘s completeness. -
VDX Unit
As the component of On-board Signaling System, it performs the function of interfacing Vital input and output signals such as emergency braking control and automatic door control.
Application
-
Domestic- Incheon Metro EMU
-
Overseas- Philippine Manila EMU
